ATZ HDMI-161SM
SGD 4,316.00
AVAILABILITY: OUT OF STOCK
16×1 HDMI 1080p60 Multiviewer SEAMLESS switcher
Out of stock
Description
This product is a high performance 16 by 1 Multi-Viewer with seamless switcher. It supports sixteen High definition input source display on one screen. As a switcher, it can also seamlessly switch the sixteen HD input freely. The product can be controled by various ways, through the front panel button control, IR control, RS232 control etc.
Features:
- Compliant with HDMI 1.3a,HDCP 1.2；
- Supports multiplexed HDMI 16-input and 1-output；
- Supports up to 1080p High Definition resolution；
- Support 16by1 Quad Multi-viewer and seamless switch；
- Support scaler up, scaler down function；
- Support multi output resolution；
- Support digital audio format LPCM/AC3/DTS；
- Support button, IR Remote,RS232 etc various controlled ways；
Additional information
| Weight | 2 kg |
|---|---|
| Dimensions | 45 × 22 × 10 cm |
Specification
| Video Bandwidth | 2.25Gbps |
| Input Ports | 16 × HDMI (Female type),1x RS232; |
| Output Ports | 1 × HDMI (Female type), |
| Audio output | PCM2, 5.1, 7.1CH, Dolby 5.1, DTS5.1 |
| Input Resolution | 480i60Hz,480p60Hz,576i50Hz,576p50Hz,720p50/60Hz, 1080i50/60Hz,1080p24/30/50/60Hz,800×600@60, 1024×768@60,1280×720@60, 1920×1080@60; |
| Output Resolution | 1080p,1080i,720p,1024×768,1360×768 |
| ESD Protection | Human Body model:±8 kV (air-gap discharge) ±4 kV (contact discharge) |
| Power Supply | 12 V/5A DC |
| Dimensions | 440 mm (W)×200 mm (D)×45 mm (H) |
| Weight | 1800 g |
| Chassis Material | Metal |
| Silkscreen Color | Black |
| Operating Temperature | 0 °C~40 °C/ 32 °F~104 °F |
| Storage Temperature | −20 °C ~ 60 °C/−4 °F ~140 °F |
| Relative Humidity | 20~90 % RH (non-condensing) |
Application Diagram
