Description

This is a FULL function USB type-C active optical cable (AOC) using optical fiber to replace copper wire as the high-speed signal transmission medium, it can perfectly  transmit USB2.0, USB3.2 Gen2 and 2-lane DP1.4 data with excellent signal quality. Compared with the traditional copper wire, it is softer, slimmer, lighter and with perfect EMI/EMC feature. And it also has better reliability performance than copper wire.

Key features of this cable include USB 3.2 compliance with SuperSpeed USB data rates of 10 Gbps, passthrough of EDID and HDCP-encrypted signals, and support for 4K/60 DisplayPort video and embedded audio signals — compatible with DisplayPort Alt mode-capable USB C host devices, the unidirectional USB-C cables transmit DisplayPort video and embedded audio signals from the host to the connected display device.

With no external power needed, its built–in active circuitry is powered by both ends of the cable, eliminating external power supply costs. With power delivery of up to 60 watts, the next-gen AOC supports various voltage profiles up to 20 volts at 3 amps and is thus able to charge a wide range of devices. With a strong zinc alloy metal shell, the attractive gold-plated contacts maintain a long-lasting, reliable electrical connection. The next-gen cable is conveniently backwards compatible with previous USB standards and also works with Thunderbolt devices (With DP Alt Mode) and is available in 3,5, 8,10 and 15m lengths, with support available for different lengths customization.

Ultra-flexible, ultra-thin 0.25″ (6.5 mm) diameter cable, these new AOC USB Type-C cables have a narrow bend radius that facilitates easier installation and reduces the possibility of cable damage. When connected to USB devices that support USB PD (Power Delivery), power flows both ways, enabling both host and peripheral devices to provide power to the far-end device. Data, video and PD can be used in high-interference environments, such as data centers and manufacturing facilities.

Features:

• Support USB3.2 Gen2, 10Gbps
• Support US2.0/1.1 High Speed and Full Speed
• Supports all major operating systems: Windows, Mac OS, and Linux
• Support 4K@60Hz in DP 2 lane at DP-Alt mode 8.1Gbps per channel
• Plug and play without driver dependent
• Requires no external power supply
• High reliability
• Thinner, ighter and softer than conventional copper cable
• Highly unaffected by EMI and RFI interference
• Support Power Delivery 60W (20V 3A)

*Remarks: This is a uni-directional cable. Please ensure correct connection with connector ends labelled with to “Host” and to “Device / Display”

Applications:

• Digital Signage
• LED signboards in streets and in stadiums
• Medical Imaging Equipment
• Airplane On-board Video System
• Home Theater
• Blue-ray, 3D video, Projector, Set-up box, DVR
• Game Consoles and Computer
• TV Broadcast Station
• Conference Room Video Equipment
• Security systems
