This armored HDMI Active Hybrid Cable for Indoor/Outdoor, is the most competitive long reach HDMI interconnection solution on the market, with strong enough 200CU stainless steel construction. It supports HDMI Data Rate 12Gbps per channel, total 48Gbps with light weight, flexible and ultra-small long-term bending radius (45mm) hybrid cable. With our advanced optical engine embedded. This HDMI Hybrid Cable provides full HDMI signal integrity, support up to 100m maximum length, plug and play. No external power required.
*Optional: Cable Reel & Waterproof cap

Features:

• 200CU stainless steel construction;
• Up to 100m Maximum Length; (Custom Length Available)
• Low Power Consumption: 250mW (max);
• Plug and Play;
• Compatible with HDMI 2.1 standard;
• Support HDCP2.3;
• Support (HDR) Dynamic HDR formats is supported;
• Support (VRR) Variable refresh rate;
• Support (QMS) Quick media switching;
• Support (QFT) Quick frame transport;
• Support (ALLM) Auto low latency Mode;
• Support (DSC) Display Stream Compression;
• Support eARC(Enhanced audio return channel);
• Support 48Gbps Bandwidth with 4Kp50/60/100/120 and 8Kp50/60;
• Hybrid 4-core optical fiber transmits TMDS signals, 7-core tinned copper transmits signalling protocol. Anti-electromagnetic interference, No attenuation.
• Support long transmission distance, the longest over 150 meters. (custom length available)
• Imported Photoelectric conversion chip to improve compatibility, stability and service life.
• Self-detecting function for EDID information;
• No loss of signal – delivering crystal clear digital images instantly;
• Supports computer resolutions to 8K@60Hz;
• Supports 16bit/24bit (RGB/YCbCr) Deep Color depth, HDR, CEC, 3D and eARC.
• Both HDMI connectors can be further protected by IP68-rated waterproof hood and caps.
• Crush Resistance: Long term100kg; Short term 200kg.
• Zinc alloy shell Anti-electromagnetic interference increase wear resistance and improve service life.

*Remarks: This is a uni-directional cable. Please ensure correct connection with connector ends labelled with “to source” and “to display”.
The cable will not be damaged, nor will it cause the connected devices to be damaged, due to wrong connection.

Applications:

• Digital Signage
• LED signboards in streets and in stadiums
• Medical Imaging Equipment
• Airplane On-board Video System
• Home Theater
• Blue-ray, 3D video, Projector, Set-up box, DVR, Game Consoles and Computer
• TV Broadcast Station
• Conference Room Video Equipment
• Security systems

Absolute Maximum Rating:

Recommended Operating Conditions:
